雙向差分壓力：

-5 .. 5 mbar --> -1000 .. 1000 mbar

差分壓力/相對壓力/表壓：

0 .. 5 mbar --> 0 .. 1000 mbar

絕對壓力：

0 .. 1000 mbar

        高精度小型化的OEM壓力傳感器模塊AMS 2710系列，輸出0…10V，工作電壓范圍寬，經過校準和溫度補償（-25 .. 85 °C），多種電氣輸出連接方式，適合工業上寬工作溫度范圍的應用。

主要參數

壓力范圍*	雙向差分壓力:	-5 .. 5 mbar --> -1000 .. 1000 mbar
	差分壓力/相對壓力/表壓:	0 .. 5 mbar --> 0 .. 1000 mbar
	絕對壓力:	0 .. 1000 mbar
	大氣壓力:	700 .. 1200 mbar
總誤差 (TEB)  (T = -25 °C .. 85 °C)	2.5 %FSO (max.)	微壓范圍 (≤ 10 mbar)
	2.0 %FSO (max.)	低壓范圍 (≤ 100 mbar)
	1.5 %FSO (max.)	標準壓力范圍 (> 100 mbar)
輸出電壓	0 .. 10 V
工作電壓	12..36 V (典型 24 V)

Overview
AMS 2710 is a series of universal, ready-to-mount OEM pressure sensor modules with 0 .. 10 V voltage output in various pressure ranges and configurations for the electrical connection. With the large supply voltage range of 12 .. 36 V the pressure sensor modules are especially suitable for industrial applications.
Due to the extensive calibration and temperature compensation AMS 2710 allows precise pressure measurements in a wide temperature range of -25 .. 85 °C.
The compact PCB pressure sensor modules from the AMS 2710 series can be easily integrated in other assemblies or used stand alone in a suitable package.


Available Pressure Ranges
? Differential (relative) pressure: 0 .. 5 mbar up to 0 .. 1 bar
? Bidirectional differential pressure: -5 .. +5 mbar up to -1 .. +1 bar
? Absolut pressure: 0 .. 1 bar
? Barometric pressure: 700 .. 1200 mbar
Custom specific pressure ranges or modifications are available on request.


Typical Applications
? Industrial process control
? Medical instrumentation
? HVAC (Heating, Ventilation, Air Conditioning)
? Vacuum monitoring
? Gas flow measurement
? Test benches
